Column
V 1000 LQ
V 1000 LQ
Tail Lift
Platform standard
- AluLite 30/40/40S - platform
- Warning flags red/white or black/yellow
- Abrollsicherung
Innenseite
- Plastic coating for platforms (incl. coated roll-stops) per m²
Außenseite
- Hinged ramps to form a stop (RTFS)
- Fixed leading edge with roll stops (FLE_RS)
- Mesh platform, V-lift (steel-insert)
- Sack barrow ramps
Lifting gear standard
- RUPD for V 1000 LQ
Operation standard
- 2-button cable control (outside) and 2-button cable control plus change-over (inside) for V-lifts
- 2-button wanderlead hand control w/o plug (as further control device)
Electrics / Sensors standard
- 12V or 24V
- Drivers cab switch with indicator OR interface ETMA Code A (V-lifts only cab switch)
Other options and accessories
- Drop-down gates V-Lift, on the column (pair)
- Drop-in gates V-Lift, (pair)
- Swing-out gates V-Lift (pair)
- Drop-side kit V-Lift
| Model | V 1000 LQ |
| Lifting capacity (kg) | 1000 |
| Maximum width over columns (mm) | 2020 - 2470 |
| Maximum floor height (mm) | 1250 |
| Platform depths (mm) | 770 - 1220 |
| Platform type | Aluminium |
| Power closure version available | yes |
| Flush side ramps available | yes |
| a (mm) | Q (kg) |
| 600 | 1000 |
| 750 | 800 |
| 950 | 600 |
| 1400 | 400 |
