up to 58,000 ft lbs
PAL Pro 58
Introducing our groundbreaking crane and crane body tailored for Class 5 applications, meticulously engineered to achieve weight reduction, extended reach, and unparalleled performance.
The PAL Pro 58 is manufactured with 12-gauge all A-60 galvaneal steel construction, a hybrid torsion box that eliminates frame and side pack deflection, and the best rust protection in the industry. Available in 11’ body configurations with standard options to meet your service truck needs, including bolt-on mounting locations for accessories like compressors and welders, headache racks, and aluminum roll-out drawer units; while providing improved lighting packages for remote work and activities during nighttime hours!
Highlights
A: NON-MARRING BOOM REST
Optional fixed non-marring boom support E-coated black.
B: INTERIOR COMPARTMENT & TRUCK BED COATING
FOR GREATER PROTECTION
Zolatone paint protection of your compartment interiors and truck bed. Ultimate Linings protection of your compartment interiors and truck bed. It resists the damage commonly caused by tools, chains, and parts and prevents the rust that comes as a result. As an added bonus, the coating is white in color and helps to brighten the interior.
C: DOOR DESIGN
ELIMINATE WELDING
Double panel doors with internal C-channel stiffeners, adhered with structural adhesive.
D: CONTINUOUS SLEWING
A continuous slewing mechanism permits an unrestricted radius of action.
A: ADVANCED LIGHTING OPTIONS
Allows for remote work and activities during nighttime hours.
- Body lights
- Crane work lights
- Cargo lights
- Interior LED lights
- Auxiliary lights
- Drip rail lights
B: CONTROL DRAWER
The control drawer houses valves and electronics with access to overrides and diagnostic display.
C: BOLT-ON HANDRAIL OPTION
FOR ADDED SAFETY
Ergonomically designed handrail option, with a stable surface to grip, for our added security against tripping or slipping hazards.
Internal Gussets
Every raised compartment comes with PALFINGER’s engineered gussets for increased protection against the body cracking in the door corner.
Work Bench
A true mechanics workbench featuring a 24” workbench bumper, receiver hitch, ¼” steel top plate, and thru compartment for additional storage.
Hybrid Torsion Box
Designed from the start for crane applications and utilizing 10ga A-60 galvanneal steel, the hybrid torsion box eliminates truck frame twists and side pack deflection.
Structural Cross-Members
Tubular 3” x 5” structural steel cross members interlace the torsion box to support compartment loads.
Outrigger Housing
Integrated outrigger tube reduces stress on the chassis frame by transferring the crane load directly to the ground.
Rear Shear Plate Body Mounts
Aluminum bolt-on auxiliary light panel with recessed license plate and camera location.
E-Tracks Inside Load Bed Space & Interior Compartments
Adjustable E-track mounting system with material hooks.
- 52" standard compartment heights with raised compartment options
- 11' standard configurations
- Treadplate cargo floor, load space walls, and compartment tops
- Hybrid torsion box and ladder frame
- PALFINGER-engineered internal gussets prevent body cracking
- Full-length channel drip rails
- Double panel doors with internal C-channel stiffeners, adhered with structural adhesive
- Non-marring boom rest
- Workbench featuring 24" work surface with 1/4" steel top plate, full width through compartment with hitch receiver tube and reinforced for 15-ton pintle plate
- Linear adjustable front mounts
- Full-length stainless steel hinges
- 316 marine grade stainless steel hinges
- A-60 galvanneal zinc-coated steel
- Rubber-mounted LED lights
- E-coat primer
- Fixed or adjustable non-marring boom support (E-Coated)
- Threaded weldment options for installing boom rest, welders, compressors, etc.
- Stabilizer options include power or manual extend configurations.
- Steel shelves or divider trays
- Aluminum roll-out drawers
- Bolt-on handrail for added safety
- Master lock system
- Low sliding roof
- Headache rack with light bar mount
- Aluminum rock guards
- LED compartment lighting
- LED work lighting
- Air compressor hose reel and FLR
- Standard and metallic topcoat paint
- And much more!
